R820 | VoLTE 4G CAT6 LTE CPE indoor Router
R820 is the latest 4G Cat6 / Cat12 LTE CPE Router indoor CPE base on Qualcomm chipset. The R820 delivers maximum speeds of 4G LTE CAT6 / 12 300/400Mbps through its Gigabit Ethernet port. It can also support RJ11 port with CSFB or VoLTE voice. Its 2.4Ghz/5GHz Dual band 11ac WiFi capability allows this device to share internet access for up to 32 clients operations simultaneously.
Categories: 4G LTE CPE Router, Mobile Broadband
Description
Features
- LTE-A CAT6 / CAT12 CA Support
- Maximum 300Mbps/400Mbps Downlink
- WiFi 2.4GHz 5.8Ghz Dual band, 802.11b/g/n/ac
- RJ45 ports: Giga Ports, 2x LANs or 1 x WAN + 1 x LAN
- Internal and external 3G/4G primary and diversity antennas
- RJ11 port for CSFB or VoLTE telephone
- Andoid / iOS App Management
- Supports FOTA and TR069
Specification
Model | R820A | ||
Dimensions | TBD | ||
Weight | TBD | ||
Form | Desk Router | ||
Communication System (WAN) | Chipset | Qualcomm MDM9x40 | |
Frequency Bands | LTE | Option1: 1/2/3/5/7/8/20/38/40/41 Option2: 1/2/3/5/7/8/28/38/40/41 Option3: 2/3/4/5/7/8/20/38/40/41 Option4: 2/3/4/5/7/8/28/38/40/41 | |
LTE CA | Option1: 1A_3A,1A_5A,1A_7A,1A_8A,1A_20A,2C,2A_5A,2A_7A,3A_3A,3C,3A_5A,3A_7A,3A_8A,3A_20A,3A_38A,5A_7A,7A_7A,7C,7A_20A,38A_38A,38C,40A_40A,40C,41A_41A,41C Option2: 1A_3A,1A_5A,1A_7A,1A_8A,1A_20A,2C,2A_5A,2A_7A,3A_3A,3C,3A_5A,3A_7A,3A_8A,3A_28A,3A_38A,5A_7A,7A_7A,7C,7A_28A,38A_38A,38C,40A_40A,40C,41A_41A,41C Option3: 2C,2A_4A,2A_5A,2A_7A,3A_3A,3C,3A_5A,3A_7A,3A_8A,3A_20A,3A_38A,4A_4A,4C,4A_5A,4A_7A,5A_7A,7A_7A,7C,7A_20A,38A_38A,38C,40A_40A,40C,41A_41A,41C Option4: 2C,2A_4A,2A_5A,2A_7A,3A_3A,3C,3A_5A,3A_7A,3A_8A,3A_28A,3A_38A,4A_4A,4C,4A_5A,4A_7A,5A_7A,7A_7A,7C,7A_28A,38A_38A,38C,40A_40A,40C,41A_41A,41C | ||
UMTS | 850/900/1900/2100 MHz | ||
GSM | 850/900/1800/1900 MHz | ||
Bandwidth | LTE Band | 1.4/3/5/10/15/20/40(2CA) MHz | |
Modulation | Downlink | QPSK/16-QAM/64-QAM/256-QAM | |
Uplink | QPSK/16-QAM/64-QAM | ||
Antenna | Internal | Primary and Diversity (UMTS Optional) | |
External | Optional: Primary and Diversity | ||
RF Power Level | LTE | Power Class 3 (23 +/-2dBm) | |
UMTS | Power Class 3 (24 +1.7/-3.7dBm) | ||
EDGE | Power Class E2 (GSM850/900: 27dBm; DCS/PCS: 26dBm) | ||
GPRS | GSM850/900 Power Class 4: 33dBm; DCS/PCS Power Class 1: 30dBm) | ||
Data Rate | 4G | 3GPP Cat. 6, Downlink/Uplink up to 300Mbps/50Mbps | |
3G | 3GPP Downlink/Uplink up to 42Mbps/5.76Mbps | ||
2G | EGPRS Class33 Downlink/Uplink up to 296Kbps/236.8Kbps | ||
WLAN | Wi-Fi | Chipset | Qualcomm QCA6174 |
Frequency | 2.4GHz, 5.8GHz | ||
Protocol | 802.11b/g/n/ac | ||
Channel | 2.4GHz: 1~13, 5.8GHz: 36~165 | ||
Antenna | Internal, 2 x 2 | ||
Data Rate | 802.11b | Up to 11 Mbps | |
802.11g | Up to 54 Mbps | ||
802.11n | Up to 300 Mbps | ||
802.11ac | Up to 867 Mbps | ||
Feature | Interface | LAN/WAN | 2xRJ45 for 2xLANs or 1xWAN+1xLAN, or 1xRJ45 for WAN/LAN |
RJ11 | Optional: CSFB or VoLTE | ||
USIM | Single, 2FF | ||
Antenna | External antenna interface supported, internal/external auto-detecting | ||
Power Jack | 12v1A interface | ||
LED | Power | Power Status Indicator | |
Network | 4G/3G/2G Network Status Indicator (3 Colors) | ||
Signal Bar | Signal Strength 4 bars | ||
Wi-Fi | Wi-Fi Status Indicator | ||
WPS | WPS Enable Status Indicator | ||
Button | Power | Power Switch | |
WPS | WPS Key | ||
Reset | Reset Key | ||
Memory | ROM | 4Gbits | |
RAM | 2Gbits | ||
WebUI | System | Connection Status | |
Statistics | |||
Device Management | |||
Power Mangement | |||
Andoid/iOS App Management | |||
Mobile Service | SMS Manager | ||
Automatic APN matching according to USIM | |||
Auto Data Connection | |||
USSD Service | |||
PIN/PUK Management | |||
Network Mode Selection(2G/3G/LTE/Auto) | |||
Router | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions | ||
Up to 15 Wi-Fi users/devices | |||
DHCP Server, IPv4/v6 | |||
Virtual Server, UPnP, DMZ, DDNS | |||
VPN Passthrough, VPN Client (Optional) | |||
DoS, SPI Firewall, IP Address Filter/Domain Filter | |||
WPS, Virtual Server, UPnP, DMZ, DDNS | |||
Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access) | |||
Access Control, Local Management, Remote Management | |||
Operation System | Windows | XP/7/8/10 | |
MAC OS | 10.7+ | ||
Linux | Ubuntu 13.04+ | ||
Browser | IE9+, Firefox, Google Chrome, Safari, Opera | ||
Environment | Power Supply | 12V1A | |
Working Temperature | 0°C to 45°C | ||
Storage Temperature | -20°C to 60°C | ||
Certification | 3GPP Compliance | CE/FCC/GCF, upon customer’s requirement | |
Meterial | RoHS |
