AceTel R875H 5G MiFi Router (WiFi 6 AX3000)
Key Performance Highlights
- Qualcomm Snapdragon SDX62 platform compliant with 3GPP Release 16
- Multi-gigabit 5G Sub-6GHz speeds up to 3.16 Gbps DL in NSA mode
- Cutting-edge Dual-Band Wi-Fi 6 AX3000 (574 Mbps 2.4GHz + 2400 Mbps 5GHz)
- High-capacity 5000mAh battery with Qualcomm Quick Charge 3.0
- Interactive 2.4-inch color TFT touch screen for real-time status & settings
- Connects up to 32 concurrent devices with USB Type-C high-speed tethering
Core Platform Specs
| Model | R875H |
|---|---|
| Category | MiFi |
| Chipset Platform | Qualcomm Snapdragon SDX62 + Qualcomm WCN6856 Wi-Fi 6 |
| WiFi Standard | WiFi 6 AX3000 (802.11ax) 2x2 MIMO Dual-Band |
AceTel R875H 5G MiFi Router — Technical Overview & Deployment Summary
Target Applications: Executive mobile professionals, broadcast video crews, VIP telecom roaming bundles, high-capacity portable hotspots, emergency response teams, and mobile content creation.
Cellular Core & Standard: Qualcomm Snapdragon SDX62 platform compliant with 3GPP Release 16, supporting 5G NR Standalone (SA) and Non-Standalone (NSA) architectures with LTE Cat 20 fallback.
Peak Data Throughput: 5G NSA Downlink up to 3.16 Gbps (Uplink up to 550 Mbps); 5G SA Downlink up to 2.16 Gbps (Uplink up to 900 Mbps); LTE Downlink up to 1.6 Gbps.
Wi-Fi 6 System: Qualcomm WCN6856 Dual-Band Wi-Fi 6 (802.11ax) 2x2 MIMO, delivering combined wireless speeds up to 3000 Mbps (574 Mbps on 2.4 GHz + 2400 Mbps on 5 GHz 160 MHz), supporting up to 32 concurrent clients.
Battery & Fast Charging: 5000mAh rechargeable Li-ion battery delivering 10–14 hours active 5G use, supported by USB Type-C Qualcomm Quick Charge 3.0.
Touch Display: Interactive 2.4-inch color TFT capacitive touch screen for intuitive network management, data usage tracking, and security configuration.
Hardware & Antenna Array: 6x internal cellular antennas supporting DL 4x4 MIMO and 2x internal dual-band Wi-Fi antennas with optimized RF isolation.
Management & Security: On-screen touch management, responsive mobile Web GUI, WPA3 security, TR-069 ACS integration, and automated FOTA remote upgrades.
FLAGSHIP MULTI-GIGABIT 5G & WI-FI 6 MOBILE HOTSPOT
The AceTel R875H is a state-of-the-art portable 5G mobile hotspot combining Qualcomm’s Snapdragon SDX62 baseband with the high-performance Qualcomm WCN6856 Wi-Fi 6 chipset. Capable of multi-gigabit download speeds up to 3.16 Gbps over 5G NR Sub-6GHz networks, the R875H provides fiber-like internet connectivity in the palm of your hand.
With Dual-Band Wi-Fi 6 AX3000 supporting 160 MHz ultra-wide channels, the R875H effortlessly powers 4K/8K livestreaming rigs, mobile production studios, and multi-user conference teams with low latency and high throughput.
INTERACTIVE 2.4-INCH COLOR TOUCH DISPLAY & ALL-DAY BATTERY
Featuring an intuitive 2.4-inch color TFT touch screen, users can view live cellular signal strength, check data consumption, view connected devices, and change Wi-Fi credentials with a single tap. A substantial 5000mAh battery with Qualcomm Quick Charge 3.0 delivers 10 to 14 hours of continuous operation, keeping executives and mobile teams productive all day without battery anxiety.
SPECIFICATIONS
| Specification Category | Parameter Details |
|---|---|
| Model Code | AceTel R875H |
| Device Form Factor | Touchscreen 5G NR + Wi-Fi 6 Mobile Hotspot |
| Baseband Modem | Qualcomm Snapdragon SDX62 Platform (3GPP Release 16) |
| Wi-Fi Processor | Qualcomm WCN6856 Wi-Fi 6 Platform |
| Cellular Standards | 5G NR Sub-6GHz (SA & NSA), 4G LTE Cat 20 |
| Peak Throughput | 5G NSA DL up to 3.16 Gbps; 5G SA DL up to 2.16 Gbps; LTE DL up to 1.6 Gbps |
| MIMO Configuration | Cellular DL 4x4 MIMO; Wi-Fi 2x2 MIMO |
| Frequency Bands | EA Version: 5G SA/NSA: n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n71/n77/n78/n79; LTE: B1/B3/B5/B7/B8/B20/B28/B32/B38/B40/B41/B42/B43 (NA bands optional) |
| Wi-Fi Standard | Dual-Band Wi-Fi 6 (802.11a/b/g/n/ac/ax), 2.4 GHz + 5 GHz |
| Wi-Fi Throughput | 574 Mbps (2.4 GHz) + 2400 Mbps (5 GHz 160 MHz) = AX3000 |
| Concurrent Users | Up to 32 connected wireless clients |
| Display Panel | 2.4-inch Color TFT Capacitive Touch Screen |
| Battery & Charging | 5000mAh Li-ion (10–14 hours active runtime); QC 3.0 Type-C Fast Charge |
| SIM Card Slot | 1x Nano-SIM (4FF) slot |
| USB Interface | USB 3.1 Gen 2 Type-C (Power charging and USB tethering) |
| Dimensions & Weight | 133.5 mm x 71 mm x 17 mm; Weight ~200 g |
| Management Protocols | Touchscreen UI, Web GUI, TR-069, FOTA Remote Upgrade |
| Compliance | CE, FCC, RoHS compliant |
APPLICATIONS & INDUSTRY USE CASES
- Executive Mobile Command: Uncompromised multi-gigabit wireless internet for traveling executives and leadership teams.
- Broadcast & Live Media Streaming: High-bandwidth, low-jitter cellular uplink for field broadcast journalists, camera crews, and podcasters.
- Pop-Up Operations & High-Tech Showrooms: Deploying instant gigabit Wi-Fi 6 for trade show booths, product demonstrations, and temporary offices.
- Premium VIP Carrier Roaming: Flagship hardware platform for Tier-1 mobile network operators’ premium 5G enterprise mobile subscriptions.
Frequently Asked Questions
Frequently asked questions about technical specifications, carrier compliance, customization, and ordering for R875H.
- What cellular speeds and Wi-Fi performance does the R875H achieve?
- Powered by the Qualcomm Snapdragon SDX62 baseband paired with Qualcomm's WCN6856 Wi-Fi 6 chip, the R875H delivers up to 3.16 Gbps 5G download speeds (NSA) and up to 3000 Mbps combined Wi-Fi 6 throughput across 2.4 GHz and 5 GHz bands.
- How long does the 5000mAh battery last and does it support fast charging?
- The integrated 5000mAh lithium-ion battery provides 10 to 14 hours of continuous high-speed 5G connectivity. It supports Qualcomm Quick Charge 3.0 via USB Type-C, recharging from 0 to 80% in approximately 90 minutes.
- What functions can be controlled on the 2.4-inch color touch screen?
- The built-in 2.4-inch color TFT touch display allows users to check real-time 5G signal strength, monitor data usage counters, view connected client devices, toggle Wi-Fi bands, and read incoming SMS messages directly without opening a browser.
- Can telecom operators customize the R875H?
- Yes, we support comprehensive OEM/ODM customization including custom casing finishes, silk-screened operator logos, branded touch screen UI themes, pre-set APNs, and customized retail gift boxes.
Request a Quote for AceTel R875H 5G MiFi Router (WiFi 6 AX3000)
Tell us your target quantity, destination market and customization needs. Our sales engineers reply within 24 hours with pricing, MOQ options and lead time.Target Model: R875H
